HDPE Baby Cones
Precision-engineered for the textile industry
High-precision HDPE baby cones for the textile and yarn winding industry. Engineered for smooth unwinding, dimensional accuracy, and durability on high-speed machines.
Our HDPE Baby Cones are manufactured using 100% virgin High-Density Polyethylene through precision injection molding. Each cone is engineered to exacting dimensional standards required by modern high-speed yarn winding machines.
The injection molding process ensures consistent wall thickness, precise taper angle, and an ultra-smooth surface finish — critical factors that prevent yarn breakage and ensure uniform unwinding at speeds exceeding 1000 meters per minute.
We use advanced steel molds with mirror-finish cavity surfaces. The cooling cycle is optimized using chilled water systems to prevent warping, shrinkage, and internal stress, ensuring every cone is dimensionally identical.
Our cones undergo 100% inspection for critical dimensions including taper angle, bore diameter, overall length, and wall thickness. Surface quality is checked under magnification to identify even microscopic imperfections.
Available in a wide range of standard sizes and taper angles. Custom dimensions, colors, and branding can be manufactured to order with minimum quantities.
Available Sizes
- 3°51' × 150mm (Standard)
- 4°20' × 170mm
- 5°57' × 200mm
- 9°15' × 240mm (Large)
- Custom taper and lengths available
Certifications
| Parameter | Value |
|---|---|
| Material | 100% Virgin HDPE |
| Manufacturing | Precision Injection Molding |
| Taper Angle | 3°51', 4°20', 5°57', 9°15' |
| Bore Diameter | 32mm / 44mm / 48mm / 57mm |
| Length Range | 100mm – 300mm |
| Wall Thickness | 1.5mm – 3.0mm (uniform) |
| Surface Finish | Mirror-smooth (Ra < 0.4 μm) |
| Weight | 15g – 80g (varies by size) |
| Color | Natural, White, Cream, Custom |
| Concentricity | < 0.1mm deviation |
| Moisture Absorption | < 0.01% |
| Operating Speed | Up to 1500 m/min |
Need HDPE Baby Cones?
Contact our team for custom specifications, bulk pricing, and fast delivery across India.
